Heta INSPIRE 45 - Inspire 55-55 H Parts List

17
1.20 Parts Inspire 55-55H Stove
Pos. No. Name Qty.
1 5013-0008 Handle 1
2 5013-0009 Set of glass clips 1
3 0021-0030 Glass 1
4 4005-0047 Door, with glass tape 1
5 0008-9086 Hinge Pin 2
6 0023-3013 Glass seal 3x8 mm 1.55 m
7 0023-3008 Door seal ø12 1.88 m
8 0023-3008 Door seal ø12 0,52 m
9 1020-0001 Handle for ash pan 1
10 1518-0106 Ash pan 1
11 0030-0020 Shaking grate 1
Pos. No. Name Qty.
12 0030-0201 Shaking grate, Ø195 mm 1
13 0015-2013 Shaking grate handle 1
14 1027-0417 Baffe support 1
15 0023-0170 Baffle plate 1
16 0023-0173 Left stone 1
17 0023-0172 Right stone 1
18 0023-0171 Left back stone 1
19 0023-0175 Right back stone 1
20 0023-0174 Bottom stone 2
21 5032-0026 Flue collar set 1
4 -
- 5 x2
7-
6 -
- 1
-9
3 -
-2 x4
-14
- 11
- 21
- 10
13 -
15 -
16 -
18 -
- 20 -
19 -
- 17
12-
8 -
