Heta INSPIRE 45 - Clearances for Inspire 40-45-55

23
Not combustible material
Combustible material
C
B
B
Min. 300
A
2.6 Clearances for installation EN 13 240 - Inspire 40-45-55
B B
C
A
A
BB
C
A
D
Min.
300
Snit A-A
A
B B
Min. 300
Snit B-B
The dimensions are the
minimum dimensions,
unless otherwise stated.
Srove
Minimum
dimensions i
mm
Distance to flamable materials
A
rear the
stove
B
at the
sides
C
door bot-
tom to
combus-
tible floor
D
to
furni-
tures
Inspire 40
120*/
190
340*/
400
170 900
Inspire 45
150*/
195
300 120 860
Inspire 55
150*/
220
420 430 1200
Clearances
- Insulated flue
* Installed with an insulated flue.
