Heta Scan-line 8 - Parts - Self-closing System

19
Pos. No. Name Qty.
1 0008-0903 Hinge pin M6x28 1
2 0008-1114 M 6 x 20 1
3 0008-1402 Nut M6 2
4 0008-9066 Quick lock Ø6 3
5 0008-9095 Spring 1,4xØ10x68,9 1
6 0016-0087 Brass bearing for self-closing 1
7 0016-0128 Extension to the gas cylinder 1
8 0025-0151 Gas cylinder 1
9 1012-0096 Spacer for pivot 1
10 1513-0129 Swivel 1
11 1513-0130 Tie rod swivel 1
Parts - Self-closing system
3
9
10
11
6
2
3
7
8
4
1
5
4
4
