SPECIFICATIONS
TG SYSTEM
Operating range 100 m (330 ft.) typical
Frequency range 400 - 470 MHz
Deviation +/- 2 kHz
HF output power 10 mW max.
Operating
temperature range
-25° to +70° C
(-18° F to 158° F)
Enclosures IP65 weatherproof (exceeds NEMA
12/13)
Transmitter antenna Built-in
TX Weight 2.1 lb (950 g) (incl. battery)
TX Size (L, W, H) 255 x 88 x 58 mm
10 x 3.5 x 2.3 inches
TX Power supply 9.6V/1200mAh NiMH rechargeable
battery pack
Operation time Up to 20 hours for CS 434, CS 447
and CS 458
Up to 18 hours for STD 402
TG DIG-V1
Functions E-Stop pushbutton
Key power switch
1 two-detent START pushbutton
1 two-detent HORN pushbutton
8 two-speed motion pushbuttons
2 two-detent OPTION pushbuttons
RECEIVER RX 14
Size 246 x 160 x 90 mm
9.7 x 6.3 x 3.5 inches
Weight 1690 g 3.7 lbs
Operating power 48/110/240 VAC 50/60 Hz (+/- 20%)
12/24 VDC (+/- 20%)
Current <100 mA
Safety features Self-monitoring E-Stop circuits
Fail-safe, spring forced E-Stop relay
Self-test during start-up and
operation
On-board diagnostic system with
indicators for RF communication,
power status, active outputs
Outputs 1 NO Potential-free E-Stop relay at
8A 30VDC/240VAC
14 NO Potential-free relays at 8A
30VDC/240VAC
RECEIVER RX 20
Size 246 x 160 x 90 mm (does not
include external antenna)
9.7 x 6.3 x 3.5 inches
Weight 1690 g 3.7 lbs
Operating power 48/110/240 VAC 50/60 Hz (+/- 20%)
12/24 VDC (+/- 20%)
Current <100 mA
Safety features Self-monitoring E-Stop circuits
Fail-safe, spring forced E-Stop relay
Self-test during start-up and
operation
On-board diagnostic system with
indicators for RF communication,
power status, active outputs
Outputs 1 NO Potential-free E-Stop relay at
8A 30VDC/240VAC
18 NO Potential-free relays at 8A
30VDC/240VAC
2 NO/NC Potential-free relays at 8A
30VDC/240VAC
BATTERY CHARGER
Charging current Normal: 200 mAh
Charge time Normal: approx. 6 hours
Temperature range -20C to +75C
Power supply DC - 12-24 VDC, polarity
protected
AC - 110-220 VAC, US/Japan or
EU plug
BATTERY
Battery type NiMh (nickel metal hydride)
Capacity (typical) 1200 mAh @ 9.6V
Typical operation
time
Up to 20 hours with one charge
(depending on TX configuration)
Memory effect None
Duty cycle Can be recharged at least 500 times
(after 500 charges, over 80% of
capacity remains and will diminish
gradually)
