Installation
20
Loosen the cable ducting strain relief (union nut).
Remove the closing plugs.
Lay the cable through the cable ducting underneath the housing
into the terminal box.
Tighten the union nut of the cable ducting and so establish the
strain relief.
Connect the power supply to the terminals PE, N, L.
To do so, insert the conductors into the round cable input at the
terminal block. Ensure that the strands are held securely in the
terminals.
To loosen the connection, insert a screwdriver into the square
opening without force in order to open the terminal. Once the
terminal has been opened, remove the conductor.
