1. PRODUCT OVERVIER
1.1. General Description
The Elfin-EG1X can meet almost all M2M needs, including automotive and personal tracking
services, wireless POS machines, smart metering, industrial PDAs, shared bikes, shared cars and
more.
The Elfin-EG1X module is an Ethernet RJ45 interface serial server with ultra-small size: 61 x 26
x 17.8mm
Elfin-EG1X Internal Frame Diagram
1.2. Device Parameters
Elfin-EG1X Technical Specifications
Item
Parameter
Wireless Parameter
GPRS Band
GSM850, EGSM900, DCS1800, PCS1900
GPRS Transmit
Power
GSM850/EGSM900: 5dbm～32.5dbm
DCS1800/PCS1900: 0dbm～29.5dbm
GPRS Receiving
Sensitivity
<-108.5dBm
GPRS Connection
Features
GPRS Multi-Slot Level is 10 (default)
GPRS Mobile Station Level B
