ModelForm FactorFormatFamilyCapacity
HUH721010AL52013.5in.SAS 512e TCGUltrastar He1010TB
HUH721010AL52043.5in.SAS 512e SEUltrastar He1010TB
HUH721010AL42003.5in.SAS 4Kn ISEUltrastar He1010TB
HUH721010AL42013.5in.SAS 4Kn TCGUltrastar He1010TB
HUH721010AL42043.5in.SAS 4Kn SEUltrastar He1010TB
HUH721010ALE6003.5in.SATA 512e ISEUltrastar He1010TB
HUH721010ALE6043.5in.SATA 512e SEUltrastar He1010TB
HUH721010ALE6013.5in.SATA 512e SED
(BDE + TCG)
Ultrastar He1010TB
The enclosure uses the following qualified solid state drives (SSDs):
Table 10: Qualified Solid State Disk Drives
ModelForm FactorFormatFamilyCapacity
SDLTODKM-400G-5CA12.5in.SAS ISESanDisk Lightning
Ascend Gen. II
400GB
SDLF1DAM-800G-1HA12.5in.SATA SESanDisk
CloudSpeed Ultra
Gen. II
800GB
8.2 Enclosure Capacity
The following section lists the capacity options per enclosure. The HDD options for capacity consider 4TB,
6TB, 8TB, and 10TB, with up to 60 HDDs per enclosure. The SSD options for capacity consider 200GB and
400GB, with up to 12 SSDs per enclosure.
Table 11: Enclosure Capacity
FamilyCapacity per Hard Disk
Drive
Max Drives Per
Enclosure
Raw capacity per
Enclosure
Ultrastar 7K60004TB (SAS)60240TB
Ultrastar 7K60006TB (SAS)60360TB
Ultrastar He88TB (SAS and SATA)60480TB
Ultrastar He1010TB (SAS)60600TB
Ultrastar He1010TB (SATA)60600TB
Ultrastar SSD800MH.B200GB (SAS)122.4TB
Ultrastar SSD1600MR400GB (SAS)124.8TB
23
8 Enclosure Capacity
User Guide 8.2 Enclosure Capacity
