1 Document Summary
The following document provides information of the agency, compliance, and certifications for countries that
allow the use and operation of the 4U60 Storage Enclosure.
1.1 Introduction
The 4U60 Storage Enclosure is a 4U, high-density drive enclosure. The enclosure is designed to house up
to a full configuration of 60 drives and to maximize the performance of these drives under all operating
conditions. For a list of compatible drives consult the HGST 4U60 Hardware User Guide.
The system contains the following high level features:
Table 1: High Level Features Specifications
Number of
Component
DetailsHardware
14U rack-mounted storage enclosure with slide
rail and cable management assembly
4U60 Storage Enclosure
Up to 22U half-width SAS Expander Canister–JBOD
application (12G version)
ESM
1Drive Board • Connects the power supplies (with
integrated fans) via power
interface board, drives, and ESM.
• Fully compliant with SAS 3.0
specification for operation up to
12Gbps.
60 qualified
drives
Full Configuration: 60 drives contained
within top accessible chassis.
3.5-inch HDD or 2.5-inch SSD
• Hot swappable
• Two status LEDs per drive slot,
Activity and Fault
• Ejector handle allows for easy
installation and removal of HDDs
and SSDs
• With carrier
2Power Supply Unit (PSU) • 2U half-width dual 1+1 redundant,
1650W AC power supplies
• 200 ~ 240 VAC (1650W) input,
47Hz – 63Hz
• +12V and +5V outputs with +5V
standby power
• 2 integrated fans powered by
redundant power rail
• Compliant with 80 Plus efficiency
Gold level
7
1 Document Summary
User Guide 1.1 Introduction
