HGST Ultrastar 7K4000 (SAS) Hard Disk Drive Specification
84
18.5.1.4 Inquiry Data Format - EVPD = 1, Page Code - 80h
Table 54: Inquiry Data - EVPD = 1 (Page Code = 80h)
• Qualifier is set to zero to indicate that the LUN specified in the Command Block is currently supported.
• Peripheral Device Type is set to zero to indicate that the device is Direct Access.
• Page Code is set to the value of the page code field in the CDB.
• Page Length is set to 16, and this field specifies the length of the following page data.
• Serial Number gives the drive serial number, right aligned.
Byte
BIT
76543210
0 Qualifier = 0 Peripheral Device Type = 0
1 Page Code = 80h
2 Reserved = 0
3 Page Length = 16 (10h)
4-19 Serial Number (ASCII)
