HGST Ultrastar 7K4000 (SAS) Hard Disk Drive Specification
75
to Illegal Request and the additional sense code set to Invalid Field in Parameter List.
18.4.3.1 Block Format - 000b
Format of the Dlist sent during the data out phase when Dlist Format is Block format (000b) and FmtData is set to one.
Table 46: Defect Descriptor - Block Format (for n + 1 defects)
The Block format of the Dlist is the LBA of each defective sector.
Note: If a Defective LBA entry, when converted to a physical sector, is equal to the physical sector of a Plist entry and
DPRY = 1, then the entry is not added to the Glist.
Byte BIT
7
6543210
0 - 3
(MSB)
Defective Logical Block Address
(LSB)
4n
4n+1
4n+2
4n+3
(MSB)
Defective Logical Block Address n
(LSB)
