2.1 PACKING
(1) PACKING PARTS LIST
Mark No. Description Part No.
2. EXPLODED VIEWS AND PARTS LIST
NOTES:
•
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•
Screws adjacent to mark on the product are used for disassembly.
Mark No. Description Part No.
1 AC Power Cord See Contrast table (2)
2 Bar Code Label MY See Contrast table (2)
3 Audio Cable (L=1.2m) PDE1003
4 Operating Instructions PRE1282
(English/French/Spanish)
5 Caution PRM1045
6 Remote Control Unit PWW1122
(R-800)
7 Battery Cover PZN1010
NSP 8 Dry Cell Battery (R03,AAA) VEM-022
9 Polyethylene Bag RHL1024
10 Packing Case PHG2365
11 Protector (F) PHA1341
12 Protector (R) PHA1342
13 Seat RHX1006
NSP 14 CDR Disc PEX1007
NSP 15 Registration Card See Contrast table (2)
NSP 16 Brochure PEX1009
17 Polystylene cover PHL1067
(2) CONTRAST TABLE
CDR-850/MY and KU/CA are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
CDR-850/MY CDR-850/KU/CA
1 AC Power Cord DDG1072 DDG1028
2 Bar Code Label MY PRW1531 Not used
2 Bar Code Label KU Not used PRW1530
NSP 15
Registration Card PEX1010 PEX1008
