6
CDR-850
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
NSP 1 SERVO DIGITAL Assy See Contrast table (2)
2 AUDIO Assy See Contrast table (2)
3 POWER Assy See Contrast table (2)
NSP 4 TRANS Assy PWZ3752
5 Jumper Wire (J) D20PYY0335E
6 Connector Assy (8P) PDE1303
7 Connector Assy PG05KK-E10
8 Connector Assy PG09KK-E35
9 Power Transformer See Contrast table (2)
10 Fuse (FU1) See Contrast table (2)
11 Screw (Steel) ABA1011
12 Screw (Steel) ABA1207
NSP 13 PCB Mould AMR1525
NSP 14 Cord Stopper DNF1128
15 Bonnet PYY1267
NSP 16 Under Base PNA2484
17 Rear Base See Contrast table (2)
NSP 18 Mecha Base PNB1591
19 Terminal Screw AKE-031
20 Connector Assy (8P) PDE1304
21 Insulator AMR7198
NSP 22 Cap VEC1810
23 Cord Clamper RNH-184
24 Screw RBA1132
NSP 25 Lead Wire Unit PDF1195
26 Connector Assy PF03PP-C16
27 Power Button PAC1918
28 Tray Panel PNW2902
29 Screw BBZ30P080FCC
30 Screw IBZ30P060FCC
31 Screw BBZ30P100FCC
32 • • • • •
33 Screw PBA1112
34 Screw IBZ30P180FCC
35 Binder PEC-107
36 Black Label PRW1470
37 Caution Label HE See Contrast table (2)
38 Caution Label See Contrast table (2)
39 65 Label See Contrast table (2)
NSP 40 Laser Caution Label See Contrast table (2)
41 INPUT Assy See Contrast table (2)
42 FCC Label See Contrast table (2)
43 DOC Label See Contrast table (2)
44 • • • • •
45 Rack Angle L PNB1604
46 Rack Angle R PNB1605
NSP 47 I/O Angle PNB1607
NSP 48 Transformer Cover PNM1338
NSP 49 Card Spacer QEC1012
50 Screw RBA1128
51 Screw BBZ40P080FCC
52 Screw BBZ40P140FZK
53 Screw IBP30P090FCC
54 • • • • •
55 Screw IBZ30P080FZK
56 Screw IBZ30P200FMC
57 Screw PMZ26P040FMC
58 Screw PMZ30P060FCC
59 Rivet RBM-003
60 Fuse Cover PNM1343
(2) CONTRAST TABLE
CDR-850/MY and KU/CA are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
CDR-850/MY CDR-850/KU/CA
NSP 1 SERVO DIGITAL Assy PWM2219 PWM2220
2 AUDIO Assy PWZ3933 PWZ3934
3 POWER Assy PWZ3937 PWZ3938
9 Power Transformer PTT1346 PTT1355
10 Fuse (FU1 : T500mA) AEK1051 Not used
10 Fuse (FU1 : 1A) Not used REK1075
17 Rear Base PNA2488 PNA2482
37 Caution Label HE PRW1233 Not used
38 Caution Label VRW1094 Not used
39 65 Label Not used ARW7050
NSP 40 Laser Caution Label Not used PRW1516
41 INPUT Assy PWZ3929 PWZ3930
42 FCC Label Not used VRW1725
43 DOC Label Not used VRW1726
