Hi-Link HLK-LD2410 User Manual

HLK-LD2410
说明书
第 13 页 共 15 页
6 Performance and Electrical Parameters
Working frequency
24GHz~ 24.25GHz
Compliant with FCC, CE, non-commission certification
standards
Power Requirements
DC 5V，Power supply capability>200mA
Average operating current
80 mA
Modulation
FMCW
interface
1 GPIO，IO level 3.3V
1 UART
target application
human presence sensor
Detection distance
0.75m～6m，adjustable
Detection angle
±60 °
Distance resolution
0.75m
Sweep Bandwidth
250MHz
Compliant with FCC, CE, non-commission certification
ambient temperature
-40 ~ 85℃
Dimensions
7mm x 35 mm
Table 2 Performance and electrical parameters table
Figure 11 Measured data of module working current
