HID EH400 - Installation and Wiring; Mounting; Wiring Connections

EdgeReader and EdgePlus
EH400, EHR40, EHRP40, EH400-K
82000-920 A.1
INSTALLATION GUIDE
2
©2009 HID Global Corporation. All rights reserved.
Mounting
Wiring
EdgeReader and EdgePlus
GND
DC In
Ethernet / PoE
Auto-Detected
CAN Termination
Resistor
(Default - IN)
3.3 VDC LED
CAN-LO (Brown)
CAN-HI (White)
GND (Black)
CAN PWR (Red)
ES400, ER40 or ERP40 (Rear View)
Hi-O Device
Ethernet
Activity LED
ATTENTION
Observe precautions for handling
ELECTROSTATIC SENSITIVE DEVICES
Junction box not included.
