FUNCTIONAL INSTRUCTIONS
Additional amplier required
OVERVIEW OF POSSIBLE INTERCONNECTION EXAMPLES
Channel Example 1 Example 2
Front / Rear with
Full Range Speakers
Separate Subwoofer-Amplier
Front 2-Way Active System
Rear with Full Range Speakers
Separate Subwoofer-Amplier
Input Mode 6 Input Mode 6
Output Mode 2 Output Mode 1
A
Speaker (FL)
HP 60 - 150 Hz
Tweeter (FL)
HP 3000-6000 Hz
B
Speaker (FR)
HP 60 - 150 Hz
Tweeter (FR)
HP 3000-6000 Hz
C
Speaker (RL)
HP 60-150 Hz
Midbass (FL)
BP:
HP 60-150 Hz
LP 3000-6000 Hz
D
Speaker (RR)
HP 60-150 Hz
Midbass (FR)
BP:
HP 60-150 Hz
LP 3000-6000 Hz
E not in use
Speaker (RL)
HP 60-150 Hz
F not in use
Speaker (RR)
HP 60-150 Hz
G Subwoofer external Amplier BP:
HP 10-30 Hz
LP 50 - 100 Hz
Subwoofer external Amplier BP:
HP 10-30 Hz
LP 50 - 100 Hz
H
Besides the interconnection example described in detail in the preceding pages the DSP amplier offers many other system
congurations. The two most common are described here in brief:
