TABLE OF CONTENT

SAFETY INSTRUCTIONS 21

Mechanical installation ....................................................................................................................22

Electrical interconnection.................................................................................................................23

INSTALLATION INSTRUCTIONS 22

Features and operational controls ...................................................................................................24

Installation of the DSP software ......................................................................................................26

Amplier conguration with the software .........................................................................................26

User Interface of the software .........................................................................................................28

Interconnection example .................................................................................................................30

Overview of the possible interconnection examples........................................................................33

Specications ..................................................................................................................................34

Warranty ..........................................................................................................................................34

FUNCTIONAL INSTRUCTIONS 24

GENERAL NOTES 34

TROUBLE SHOOTING 35

PLEASE KEEP THIS MANUAL FOR LATER PURPOSES!

This symbol shows you important notes on the following pages. Follow these notes necessarily, otherwise damages of the

device and on the vehicle as well as serious injuries may be caused.

NOTE

SCOPE OF DELIVERY

1 x TRX5005 DSP Amplier

1 x Remote Controller with LED Display, incl. Connection Cable

1 x USB Cable, A- to Mini-B Connector, 5 m

1 x CD-ROM with M-CONTROL Software

1 x Owner‘s Manual (German/English)

1 x Spare Fuse

Due to the ongoing development of this device, it is possible that the information in this manual is in-

complete or is not matching to the delivery status.
