28
FUNCTIONAL INSTRUCTIONS
4
1 6
5
7
8
9
2
3
1
USER INTERFACE OF THE SOFTWARE
Here you are able to adjust many settings to customize your sound system, which are immediately audible in real time via the DSP amp-
lier. Once you are done with the conguration of a setting, it can be transferred to a storage space on the DSP amplier. You can store
up to 10 different settings and select them with the remote control at any time during operation.
The following section describes the functions of the M-CONTROL user interface.
1. File - Dropdown menu:
• PC Contrl: Opens the RS232 Setting dialog.
• Open: Opens a previously, on the PC saved setting.
• Save: Saves a setting in a le on the PC with the currently used
le name. If no le name has been previously chosen
the Save File dialog automatically asks for it.
• SaveAs: Saves a setting under a given le name.
• Factory Setting: Resets all settings to factory default.
• Class-D AMP Setting: Without function.
• Write To Device*: Saves the setting on the DSP device. The following
selection window shows in which storage space the setting can be stored.
• Chose under Select Save Place a storage space and conrm your
selection with Save to Flash.
Note: Save the settings always numerological (POS 1, POS 2, POS 3,…), to access
them with the remote controller. No save space must be empty in between, otherwise, these settings are not accessable. See dialog
window above.
• Read from Device*: Reads from the selected setting on the remote control from the DSP.
• Exit: Quits M-CONTROL.
* Important: Therefore the enclosed remote controller must necessarily be connected to the DSP amplier.
