Product Overview and Specifications
4 Hog iPC Handbook
Features
Note that some of the following features will not be available on the Hog iPC console when
operating the classic Hog
®
2PC software. In addition, some features may be the result of
future Hog
3PC software releases.
DMX Control Capability
• 2048 to 4096 DMX-512 channels (depending on number of external USB DMX Widgets)
• Unlimited number of simultaneous crossfades
• Thousands of cues, cuelists, cue parts, chases, effects, groups, palettes, pages, macros
Hardware
• Console construction of precision-machined aluminum with a tough wear-resistant
anodized finish.
• Four universes of DMX output direct from the console, expandable to eight with USB
DMX Widgets or USB DMX Super Widget
• Two 12 inch high-brightness color touchscreens, with adjustable viewing angles
• Third monitor or touchscreen capabilities when connected to DVI port
• Backlit trackball with four buttons that can be configured for cursor and position control
• Ten Playback faders with familiar Wholehog 3 playback controls (Choose, Go, Pause &
Flash)
• Integrated PC motherboard operating via Windows XP Embedded
• Internal 40 gigabyte hard drive, and re-writeable CD-ROM drive
• Five Universal Serial Bus ports for touchscreens, external drives, printer, and Wholehog
3 accessories (e.g. playback wing, expansion wing, and additional USB DMX Widgets)
• Ethernet connector allows communications with Hog 3PC computers, Hog iPC consoles,
and Wholehog 3 console systems
• Realtime clock
• Dual LED desklights and feedback LED’s dimmable
• Designed for easy maintenance
• Custom integrated roadcase
• Auto-ranging mains input (90-250 VAC)
Connectivity
• Supports up to four USB Playback Wings
• Supports Wholehog 3 Expansion Wing
• MIDI Input, Output, and Thru supports Midi Show Control and Midi Time Code
• Single Linear Time Code (SMPTE) input via 3 pin female XLR connector
