High Tech Pet Armor Flex - Track Height and Riser Adjustment

6
Fig 4
STEP 4: Determine your patio track height
Measure from the inside bottom of your sliding glass door track to
the inside top as shown in Figure 4.
STEP 5: For short installations, remove Riser Extension
If your sliding glass door frame measures between 75”
and 77” high, remove the Riser Extension on the
Bottom Panel Assembly by unscrewing the connector
screws on each side of the Riser Extension as shown in
Figure 5. The aluminum Riser Extension may be
recyled. For patio doors taller than 77”, do not
remove the extension.
Fig 5
75” – 77”
Remove Riser Extension
(Step 5)
77” – 80 1/4”
Do Not Remove Riser
Extension
(Skip Step 5)
