Errs 00127 XTRIM RECAL CALIB LOGIC XLOCK TUNE DPLL
where the integer value represents the error flags word. Bits are...
Bit Value Fla
g
Meanin
g
0 1
XTRIM
VCXO trim value lost
1 2
RECAL
saved setup recall failed
2 4
CALIB
calibration table lost; default cals are used
3 8
LOGIC
internal lo
g
ic erro
r
4 16
XLOC
K
VCXO failed to lock to external source
5 32
TUN
E
powerup DPLL calibration erro
r
6 64
DPLL
DPLL stabilit
y
erro
r
If any error bits are set, the string will also explicate the error bits in text. The "power" LED
will turn yellow if any error bits are up.
The ERrors 0 command will clear the error flags word.
4.6.12. VERBOSE COMMAND
The VErbose 1 command places the T560 in verbose mode, where commas are included
in all long numeric strings that are returned. This mode makes time settings and 32-bit
integers easier to read but may not be compatible with external software.
The VErbose 0 command will cancel verbose mode.
VErbose alone will query this setting.
4.6.13. HELP COMMANDS
The HElp command, with no arguments, will display a short command summary, listing
top-level commands. Specific commands will be explained with requests of the form HElp
TRigger and such.
HElp
return
g
eneral HELP messa
g
e
HElp CHannels
return help on channel operations
HElp TRigger
return Tri
gg
er help
HElp CLock
return Clock help
HElp BUrst
return Burst help
HElp GAte
return Gate help
HElp MIsc
return miscellaneous help
4.6.14. STATUS COMMAND
The STatus query returns a full report of T560 settings. A typical report is shown below.
Verbose mode was enabled. The status shown is the default setup.
