6
Step 5. Please remove these screws from each of the M.2 slots.
Step 6. Gently insert the NVMe SSD into the M.2 slot.
Note:
Please make sure all disks are clean before you insert them
into the slot to avoid unexpected situations.
Step 7. Refasten the screw to secure the NVMe SSD.
Repeat Steps 5 to 7 to install the remaining NVMe SSDs.
The following example shows eight Gen4 NVMe SSDs installed into
Ports 1-8:
