RocketRAID 2640X4 Web-RAID Management Interface
5-9
Controller ID
Which controller /card the disk is attached to.
Port #
Port location of the hard disk
Device Serial Number
Serial number of the hard disk
RAID
RAID/Non-RAID status
F
Temperature (in Fahrenheit) of the hard disk (Celsius is displayed under the SMART
status)
Bad Sectors/Found & Repaired
The card is capable of repairing bad sectors – a summary of this activity is presented
here.
Device Status
OK means the disk is in a healthy state. A Failed status suggests the disk was taken
offline (due to a RAID, SMART or sector failure).
Schedule
Click on the blue “Schedule” link to access the Event menu.
S.M.A.R.T Status
You can view S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology)
data about a particular hard disk to help troubleshoot problems that occur. You can
also setup periodically S.M.A.R.T. status checking to send notification messages
when S.M.A.R.T. thresholds are exceeded.
To view the S.M.A.R.T status of a hard disk:
1. Select “Manage - Device” from the menu.
2. Click the “SMART” link to display the S.M.A.R.T information page.
