English
33
Table 2
Indications of the pilot lamp
Pilot lamp
(red)
Before
charging
Blinks
Lights for 0.5 seconds. Does not
light for 0.5 seconds. (off for
0.5 seconds)
While
charging
Lights
Lights continuously
Charging
complete
Blinks
Lights for 0.5 seconds. Does not
light for 0.5 seconds. (off for
0.5 seconds)
Overheat
standby
Blinks
Lights for 1 second. Does not
light for 0.5 seconds. (off for
0.5 seconds)
Battery overheated.
Unable to charge.
(Charging will
commence when
battery cools)
Charging
impossible
Flickers
Lights for 0.1 seconds. Does not
light for 0.1 seconds. (off for
0.1 seconds)
Malfunction in
the battery or the
charger
● Regarding the temperatures and charging time of the battery.
The temperatures and charging time will become as shown in Table 3.
Table 3
Charger
Battery
UC18YKSL UC18YFSL
Charging voltage V 14.4 – 18
Weight kg 0.35 0.5
Temperatures at which the battery can be
recharged
0oC – 50oC
Charging time for battery capacity, approx.
(At 20oC)
1.5 Ah
2.0 Ah
2.5 Ah
3.0 Ah
4.0 Ah
5.0 Ah
min.
min.
min.
min.
min.
min.
40
60
75
90
120
150
22
30
35
45
60
75
Number of battery cells 4 – 10
NOTE
The recharging time may vary according to temperature and power source voltage.
