HIKVISION Digital Video Recorder Quick Start Guide

Quick Start Guide of Digital Video Recorder
20
Table 3 Specification for DS-7200HQHI-SH
Model
DS-7204HQHI-SH
DS-7208HQHI-SH
Video/Audio
input
Video compression
H.264
Analog and HD-TVI
video input
4-ch
8-ch
BNC interface (1.0Vp-p, 75 Ω)
Supported camera types
720P25, 720P30, 720P50, 720P60, 1080P25, 1080P30, CVBS
Audio compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 KΩ)
Two-way audio in
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the 1st channel of audio input)
Video/Audio
output
HDMI / VGA output
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60
Hz
Encoding resolution
Main stream: 1080P / 720P / VGA / WD1 / 4CIF / CIF
Sub-stream: WD1(non-real-time) / 4CIF(non-real-time) / CIF / QCIF / QVGA
Frame rate
Main stream: 1/16 fps ~ Real time frame rate
Sub-stream: 1/16 fps ~ Real time frame rate
Video bitrate
32 Kbps-10 Mbps
Audio output
1-ch, RCA (Linear, 1KΩ)
Audio bitrate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous playback
4-ch
8-ch
Playback resolution
1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF
Network
management
Remote connections
128
Network protocols
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS,
iSCSI, UPnP™, HTTPS
Hard disk
SATA
1 SATA interface
2 SATA interfaces
Capacity
Up to 4 TB capacity for each disk
External
interface
Network interface
1; 10M / 100M / 1000M self-adaptive Ethernet interface
Serial interface
1; standard RS-485 serial interface, half-duplex
Alarm in/out
4/1
8/4
USB port
2 × USB2.0
General
Power supply
12V DC
Consumption
(without hard disks)
≤ 15W
≤ 30W
Working temperature
-10 ºC ~+55 ºC (14 ºF ~ 131 ºF)
Working humidity
10% ~ 90%
Chassis
1U chassis
380mm 1U chassis
Dimensions
(W × D × H)
315 × 242 × 45mm
(12.4 × 9.5 × 1.8 inch)
380 × 290 × 48mm
(15.0 × 11.4 × 1.9 inch)
Weight
(without hard disks)
≤ 1.5Kg (3.3lb)
≤ 2Kg (4.4lb)

HIKVISION Digital Video Recorder Specifications

General

Audio system	2-way
Product color	Black
Channels quantity	4 channels
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265 Pro, H.265 Pro+
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x480, 704x576
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Audio input	RCA
RS-485 ports	1
USB 2.0 ports quantity	2
DC voltage	12 V
Power consumption (typical)	18 W
HDD interface	Serial ATA, Serial ATA II, Serial ATA III
Maximum HDD capacity	10000 GB
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF

Weight and Dimensions

Depth	242 mm
Width	315 mm
Height	45 mm
Weight	1160 g
