Table 6 Specification for DS-8100HGHI-SH
Model
DS-8104HGHI-SH
DS-8108HGHI-SH
DS-8116HGHI-SH
Video/Audio
input
Video compression
H.264
Analog and HD-TVI
video input
4-ch
8-ch
16-ch
BNC interface (1.0Vp-p, 75 Ω)
Supported camera types
720P25, 720P30, 720P50, 720P60, 1080P25, 1080P30, CVBS
Audio compression
G.711u
Audio input
4-ch
8-ch
16-ch
RCA (2.0 Vp-p, 1 KΩ)
Two-way audio in
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI / VGA output
1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution
Main stream: 1080P (non-real-time) / 720P / WD1/ VGA / 4CIF / CIF
Sub-stream: WD1(non-real-time) / 4CIF(non-real-time) / CIF / QCIF / QVGA
Frame rate
Main stream: 1/16 fps ~ Real time frame rate
Sub-stream: 1/16 fps ~ Real time frame rate
Video bitrate
32 Kbps-6Mbps
Audio output
2-ch, RCA (Linear, 1KΩ, for VGA output and CVBS output respectively)
Audio bitrate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous playback
4-ch
8-ch
16-ch
Playback resolution
1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF
Network
management
Remote connection
128
Network protocols
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI,
UPnP™, HTTPS
Hard disk
Type
8 SATA interfaces for 8 HDDs; 1 eSATA interface
Capacity
Up to 4 TB capacity for each disk
External
interface
Network interface
2; 10M / 100M / 1000M self-adaptive Ethernet interfaces
Serial interface
RS-232, RS-485, Keyboard;
USB port
3 × USB2.0
Alarm in / out
16 / 4
General
Power supply
100 ~ 240VAC, 47 ~ 63HZ
Consumption
(without hard disks)
≤ 30W
≤ 40W
≤ 55W
Working temperature
-10 ºC ~+55 ºC (14 ºF ~ 131 ºF)
Working humidity
10% ~ 90%
Chassis
19-inch rack-mounted 2U chassis
Dimensions (W × D × H)
445 × 470 × 90 mm (17.5 × 18.5 × 3.5 inch)
Weight
(without hard disks)
≤8Kg (17.6 lb)

HIKVISION Digital Video Recorder Specifications

General

Audio system	2-way
Product color	Black
Channels quantity	4 channels
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265 Pro, H.265 Pro+
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x480, 704x576
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Audio input	RCA
RS-485 ports	1
USB 2.0 ports quantity	2
DC voltage	12 V
Power consumption (typical)	18 W
HDD interface	Serial ATA, Serial ATA II, Serial ATA III
Maximum HDD capacity	10000 GB
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF

Weight and Dimensions

Depth	242 mm
Width	315 mm
Height	45 mm
Weight	1160 g
