HIKVISION DS-2CD1023G0-IU User Manual

Network Bullet Camera·Quick Start Guide
25
Activating the Camera
You are required to activate the camera first by setting a strong
password for it before you can use the camera.
Activation via Web Browser, Activation via SADP, and Activation via
Client Software are all supported. We will take activation via SADP
software and Activation via Web Browser as examples to introduce
the camera activation.
Note:
Refer to the User Manual of Network Camera for Activation via
Client Software.
Activation via Web Browser
Steps:
1. Power on the camera. Connect the camera to your computer or
the switch/router which your computer connects to.
2. Input the IP address into the address bar of the web browser, and
press Enter to enter the activation interface.
Notes:
 The default IP address of the camera is 192.168.1.64.
 The computer and the camera should belong to the same
subnet.
 For the camera enables the DHCP by default, you need to use
the SADP software to search the IP address.

HIKVISION DS-2CD1023G0-IU Specifications

General

Type	IP security camera
Placement supported	-
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Bluetooth	No
Number of users	32 user(s)
Networking standards	IEEE 802.3af
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
Ethernet LAN (RJ-45) ports	1
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Black, White
Housing material	Metal, Plastic
International Protection (IP) code	IP66
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Angle of rotation	360 °
Camera shutter speed	1 - 1/100000 s
Minimum illumination	0.028 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	3.6 W
Power consumption (Power over Ethernet (PoE))	4 W
Fixed focal length	2.8 mm
Maximum aperture number	2
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.265, M-JPEG
Noise reduction technology	3D noise reduction

Weight and Dimensions

Depth	66.2 mm
Width	67.8 mm
Height	177.6 mm
Weight	270 g
Package depth	121 mm
Package width	216 mm
Package height	118 mm
Package weight	470 g
