HIKVISION DS-2CD1023G0-IU User Manual

Network Bullet Camera·Quick Start Guide
6
the restrictions applied to the location and about any
precautions that shall be taken.
● Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
● In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
● Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 12 VDC according
to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
● Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
● Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
● If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
● Make sure the power supply voltage is correct before using the
camera.
● Do not drop the camera or subject it to physical shock.

HIKVISION DS-2CD1023G0-IU Specifications

General

Type	IP security camera
Placement supported	-
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Bluetooth	No
Number of users	32 user(s)
Networking standards	IEEE 802.3af
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
Ethernet LAN (RJ-45) ports	1
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Black, White
Housing material	Metal, Plastic
International Protection (IP) code	IP66
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Angle of rotation	360 °
Camera shutter speed	1 - 1/100000 s
Minimum illumination	0.028 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	3.6 W
Power consumption (Power over Ethernet (PoE))	4 W
Fixed focal length	2.8 mm
Maximum aperture number	2
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.265, M-JPEG
Noise reduction technology	3D noise reduction

Weight and Dimensions

Depth	66.2 mm
Width	67.8 mm
Height	177.6 mm
Weight	270 g
Package depth	121 mm
Package width	216 mm
Package height	118 mm
Package weight	470 g
