HIKVISION DS-2CD2043G0-I User Manual

Network Bullet Camera·Quick Start Guide
5
2006/66/EC (battery directive): This product contains
a battery that cannot be disposed of as unsorted
municipal waste in the European Union. See the
product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier
or to a designated collection point. For more information, see:
www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.

HIKVISION DS-2CD2043G0-I Specifications

General

Type	IP security camera
Languages support	Multi
Number of languages	32
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Ethernet LAN (RJ-45) ports	1
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67
Total megapixels	4 MP
Gain control type	Auto
Maximum resolution	2688 x 1520 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	320 x 240, 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
Pan range	0 - 360 °
Tilt angle range	0 - 90 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Focus	Manual
Fixed focal length	2.8 mm
Maximum aperture number	1.6
Minimum aperture number	1.2
Alert notification type	E-mail
Intelligent Video Surveillance (IVS) system features	Face detection, Intrusion
Lens mount interface	M12
Behavior analysis	Intrusion detection, Line crossing detection
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Number of users	32 user(s)
User access level	Administrator, Operator, User
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
DC output current	0.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6 W
Power consumption (Power over Ethernet (PoE))	7.5 W
Minimum RAM	1000 MB
Minimum processor	2 GHz
Minimum system requirements	Operating System: Microsoft Windows XP SP1 and above version; CPU: 2.0 GHz or higher; RAM: 1G or higher; Display: 1024×768 resolution or higher; Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version

Weight and Dimensions

Length	155.03 mm
Weight	420 g
Diameter	70 mm
Package depth	121 mm
Package width	216 mm
Package height	118 mm
Package weight	700 g
