HIKVISION DS-2CD2047G1-L

Network Bullet Camera·Quick Start Guide
17
Note:
Drill the cable hole, if adopting ceiling outlet to route the cable.
Ø 84
3-Ø 4
Ø 40
Ø 70
Ø 70
3-M4
Figure 2-5 Drill Template
3. Take apart the junction box, and align the screw holes of the bullet
camera with those on the junction box's cover.
4. Fix the camera on the junction box's cover with three PM4 × 10
screws.
Figure 2-6 Fix the Camera on Junction Box's Cover
