HIKVISION DS-2CD2423G0-I User Manual

Network Cube Camera·Quick Start Guide
7
Warnings
● Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
● In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
● The power source should meet limited power source or PS2
requirements according to IEC 60950-1 or IEC 62368-1
standard.
● Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
● Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
Warnings
Cautions
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

HIKVISION DS-2CD2423G0-I Specifications

General

Number of lenses	1
Fixed focal length	2.8 mm
Maximum aperture number	2
Minimum aperture number	1.2
Noise reduction	Yes
Total megapixels	2 MP
Gain control type	Auto
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	320 x 240, 352 x 240, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Sensor type	CMOS
Optical sensor size	1/2.7 \
Pan range	0 - 360 °
Tilt angle range	0 - 90 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Type	IP security camera
Languages support	Multi
Number of languages	32
Placement supported	Indoor
Connectivity technology	Wired
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Alert notification type	E-mail
Intelligent Video Surveillance (IVS) system features	Face detection
Number of users	32 user(s)
User access level	Administrator, Operator, User
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Sample rate	48 kHz
Voice codecs	G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Behavior analysis	Intrusion detection, Line crossing detection
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
DC output current	0.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6 W
Power consumption (Power over Ethernet (PoE))	7 W
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	10 m
Form factor	Cube
Mounting type	Desk
Product color	Black, White
Housing material	Plastic

Weight and Dimensions

Depth	32.6 mm
Width	65.2 mm
Height	102.8 mm
Weight	128 g
