Network Cube Camera·Quick Start Guide
17
No. Description
3 1 RJ45 10M/100M self-adaptive Ethernet port & PoE
4 Power Interface (12 VDC)
5 Speaker
6 Microphone
7 Lens
8 Indicator
● Solid red: the camera is starting
● Slow flashing red: the network
connection failed
● Quick flashing red: the memory card
error or other malfunctions
● Flashing blue: the camera is
connected to the network successfully
● Quick flashing blue/Flashing red and
blue alternately: the camera starts
successfully and waits Wi-Fi
configuration
9 PIR(Passive Infrared) sensor
10 IR LED
Note:
The indicator varies according to different device models.
