Network Dome Camera·Quick Start Guide
13
13
1.1.2 Cable Description
Cable description of the Type I network dome camera is shown
below.
Note: Cables vary according to different models as the figures below.
Figure 1-3 Cable Description of Type I Camera (1)
10
12
9
14
13
Figure 1-4 Cable Description of Type I Camera (2)
