HIKVISION DS-2CD2722FWD-IS - Cable Description

Network Dome Camera·Quick Start Guide
16
16
Overview of Type II Camera
No.
Description
1
Bubble
2
Black Liner
3
Lens
4
Reset
5
Memory Card Slot
1.2.2 Cable Description
Cable description of the Type II network dome camera is shown
below.
Note: Cables vary according to different models as the figures below.
D C
1
2
V
I N
6
7
Figure 1-7 Cable Description of Type II Camera (1)
