Network Camera User Manual
132
a. Select the Picture Quality and Resolution from the drop-down list.
b. Check Background Upload to upload the background image.
Note: Background upload is only available for face capture camera.
Camera Information:
You can set the Device No. and Camera Info. for the camera, which can be overlaid
on captured picture.
Text Overlay Information:
You can check desired items and adjust their order to display on captured pictures.
Shield Region
The shield region allows you to set the specific region in which the face capture does
not work. Up to 4 shield regions are supported.
Steps:
1. Click to draw shield area by left click end-points in the live view window,
and right click to finish the area drawing.
Notes:
● Polygon area (4 to 10 sides) sides is supported.
● Click to delete the drawn areas.
● If the live view is stopped, there is no way to draw the shield regions.
Draw Shield Area
2. Click Save.
