Network Fisheye Camera·Quick Start Guide
16
16
Wall
Base Plate
Camera
Bayonet Joint
Bayonet Joint
Bayonet Joint
Install the Camera Figure 2-3
5. To disassemble the camera: Press the Push button on the base
plate, rotate the camera anticlockwise, and then you can remove
the camera from the base plate.
Wall
Disassemble the Camera Figure 2-4
