Network Fisheye Camera·Quick Start Guide
19
19
Drill Template B Figure 2-7
2. Fix the slant mounting base to the wall with the screws.
Mounting Base
Wall
Fix the Slant Mounting Base Figure 2-8
3. Align the screw holes on the slant mounting base and the base
plate, and then secure the base plate on the slant mounting base
with the two supplied screws.
