Network Fisheye Camera·Quick Start Guide
24
5. Fix the mounting base to the wall with the screws.
Wall
Fix the Mounting Base Figure 2-15
6. Re-install the main body of the bracket to the mounting base, and
fix it with the screw.
Wall
Bracket
Screw
Re-install the Bracket Figure 2-16
