Quick Guide of Network Camera

Chapter 3 Preview via WEB browser

Note: The default IP of network cameras is ‘192.0.0.64’ with ‘admin’ as the administrator, ‘12345’ as

the password, and ‘8000’ as the default port.

For monitoring camera images, a computer running the Microsoft Windows Operating System and

Internet Explorer (Version 6.0 or later) are required. In this manual, we take Windows XP and IE 6.0

for example.

This chapter describes how to view the video from the camera via web browser, and operate as

following:

Figure 3.1

1. Open the IE browser, set the security level to [Medium] in

*Tools/InternetOptions/Security/Custom Level…+

Other manuals for HIKVISION DS-2CD7164-E

Questions and Answers:

Need help?

Do you have a question about the HIKVISION DS-2CD7164-E and is the answer not in the manual?

General

Type	IP security camera
PTZ control	Yes
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Dome
Product color	White
Protection features	Vandal proof
International Protection (IP) code	IP66
Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 960, 1280 x 720 (HD 720)
Pan range	-15 - 15 °
Tilt angle range	0 - 90 °
Angle of rotation	15 °
Minimum illumination	0.01 lx
Field of view (FOV) angle	73 °
Sensor type	CMOS
Optical sensor size	1/3 \
Optical zoom	- x
Zoom capability	-
Focus adjustment	2.0
Fixed focal length	8 mm
Password protection type	User
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, QoS
Ethernet LAN (RJ-45) ports	1
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	4 W
Operating temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
