3 Menu Description
Follow the steps below to call the menu.
Note:
The actual display may vary with your camera model.
Steps:
1. Connect the camera with the TVI DVR, and the
monitor, shown as the figure 3-1.
Figure 3-1 Connection
2. Power on the camera, TVI DVR, and the monitor to
view the image on the monitor.
3. Click PTZ Control to enter the PTZ Control interface.
4. Call the camera menu by clicking button, or call
the preset No. 95.
MAIN
MENU
AE
MENU
WB
RESET
LANGUAGE
FORMAT
SAVE & EXIT
DAY/NIGHT
VIDEO
SETTINGS
BRIGHTNESS
EXPOSURE MODE
AGC
DWDR
RETURN
IMAGE MODE
CONTRAST
SHARPNESS
COLOR GAIN
DNR
MIRROR
RETURN
Figure 3-2 Main Menu Overview
5. Click the direction arrow to control the camera.
1). Click up/down direction button to select the
item.
2). Click Iris + to confirm the selection.
3). Click left/right direction button to adjust the
value of the selected item.
3.1 FORMAT
You can set the video format to 1080P@25fps or
1080P@30fps.
3.2 LANGUAGE
English is available.
3.3 MAIN MENU
AE (Auto Exposure)
You can adjust BRIGHTNESS, EXPOSURE MODE, AGC,
DWDR in this section.
BRIGHTNESS
To Next Page
