UM DS-2CE17H0T-IT3F 052220NA 10
Figure 8, Connection
2. Power on the analog camera, TVI DVR, and the
monitor to view the image on the monitor.
3. Click PTZ Control to enter the PTZ Control
interface.
4. Call the camera menu by clicking the
button or calling preset No. 95.
Figure 9, Main Menu Overview
5. Click the direction arrow to control the
camera.
1) Click up/down direction button to select
the item.
2) Click Iris+ to confirm the selection.
3) Click left/right direction button to adjust
the value of the selected item.
To Next Page
