UM DS-2CE17H0T-IT3F 052220NA 14
SMART IR: Adjusts the light to its most suitable
intensity and prevents the image from
overexposure. The SMART IR value can be
adjusted from 1 to 3. The higher the value, the
more obvious the effect.
D->N THRESHOLD (Day to Night Threshold):
Controls the sensitivity of switching the day
mode to the night mode. You can set the value
from 1 to 9. The larger the value, the more
sensitive the camera.
N->D THRESHOLD (Night to Day Threshold):
Controls the sensitivity of switching the night
mode to the day mode. You can set the value
from 1 to 9. The larger the value, the more
sensitive the camera.
VIDEO SETTINGS
Move the cursor to VIDEO SETTINGS and click Iris+ to
enter the submenu. IMAGE MODE, WHITE BALANCE,
BRIGHTNESS, CONTRAST, SHARPNESS, SATURATION,
DNR, and MIRROR are adjustable.
Figure 13, Video Settings
IMAGE MODE: Adjusts the image saturation. You
can set it to STD (Standard), or HIGH-SAT (High
Saturation).
WHITE BALANCE: The white rendition function of
the camera, adjusts the color temperature
according to the environment. It can remove
unrealistic color casts in the image. You can set
the mode to AUTO or MANUAL.
AUTO: White balance adjusts automatically based
on the scene illumination color temperature.
MANUAL: You can adjust the R-GAIN and B-GAIN
value to correct colors manually.
