UM DS-2CE17H0T-IT3F 052220NA 6
1 Introduction
Product Features
The main features are as follows:
High Performance CMOS Sensor
OSD Menu with Configurable Parameters
Smart IR
3-Axis Adjustment
Overview
Figure 1, Camera Overview
NOTE: Press and hold the switch button for five
seconds to switch the video output. Four
kinds of video outputs are available: TVI,
AHD, CVI, and CVBS.
2 Installation
Before You Start
Make sure that the device in the package is in
good condition and all the assembly parts are
included.
Make sure that all the related equipment is
powered off during the installation.
Check the specification of the products for the
installation environment.
Check whether the power supply is matched with
your power output to avoid the damage.
Make sure the wall is strong enough to withstand
three times the weight of the camera and the
mount.
If the product does not function properly,
contact your dealer or the nearest service
center. Do NOT disassemble the camera for repair
or maintenance yourself.
Power Cord
Video Cable
Bracket
Main Body
To Next Page
