HIKVISION DS-2DB4236I-CWX Quick Start Guide

Explosion-proof IR Zoom Bullet Camera·Quick Start Guide
12
Pedestal
Screws
Mounting
Base
Figure 2-5 Install the Pedestal to Camera
3. Install the PT joint to the wall mounting bracket with four supplied
screws.
Note:
Adjust the panning position of the PT joint to desired angle when
installing.
Pan
:
-
45
° to 45
°
Figure 2-6 Screw the PT Joint to Wall Mounting Bracket
4. Align the screw holes on pedestal with those on PT joint. Fix the
camera to the bracket.
