Explosion-proof IR Zoom Bullet Camera·Quick Start Guide
13
Note:
Adjust the tilting position of the camera to desired angle when
installing. Use at least three screws on each side of the PT joint to
secure the camera.
Figure 2-7 Fix the Camera
5. Install the mounting base of the wall mounting bracket.
1). Mark the screw holes on desired mounting place on wall
according to the dimension of the mounting base.
118
4- Ø16
290
Figure 2-8 Mounting Base Dimension of the Bracket Type I (mm)
