2). Drill four screw holes for expansion bolts with a Φ16 mm drill.
3). Insert the expansion bolts (M12 × 120) and fix the mounting
base at the direction indicated by the "UP" mark.
Figure 2-9 Install the Mounting Base of the Bracket
6. Fix the wall mounting bracket, together with the camera, to the
mounting base of the bracket.
1). Use safety rope to hook the camera and the mounting base of
the bracket.
2). Hang the bracket to the bolts on the mounting base. Secure
the bracket with nuts, spring washers and flat washers.
