© Hikvision
Figure 4-5 Auxiliary Functions
Table 4-4 Descriptions of Auxiliary Functions
Click the button to enable/disable the light supplement of
the camera.
Click the button to move the wiper once. The function
can only be realized with wiper device.
This function is reserved.
Click the button and the lens operates the movements for
initialization.
Steps:
1. Click on the toolbar of live view interface.
2. Click a moving object in the live video. The camera
will track the object automatically.
Note:
The function is only supported by certain camera models.
Click to save the current view as the preset No. 32
and start park at the current position.
4.5.3 Setting/Calling a Preset
Purpose:
A preset is a predefined image position. For the defined preset, you can click the calling button to
quickly view the predetermined image position.
Setting a Preset:
Steps:
1. In the PTZ control panel, select a preset number from the preset list.
Figure 4-6 Setting a Preset
To Next Page
