User Manual of Network Mini PTZ Camera
Chapter 2 Network Connection
You shall acknowledge that the use of the product with Internet access might be
under network security risks. For avoidance of any network attacks and
information leakage, please strengthen your own protection. If the product does
not work properly, please contact with your dealer or the nearest service center.
To ensure the network security of the speed dome, we recommend you to have
the speed dome assessed and maintained termly. You can contact us if you need
such service.
Before you start:
If you want to set the network PTZ camera via a LAN (Local Area Network),
please refer to Section 2.1.
If you want to set the network PTZ camera via a WAN (Wide Area Network),
please refer to Section 2.2.
2.1 Setting the Network PTZ Camera over the LAN
Purpose:
To view and configure the PTZ camera via a LAN, you need to connect the network
PTZ camera in the same subnet with your computer, and install the SADP or client
software to search and change the IP of the network PTZ camera.
For the detailed introduction of SADP, please refer to Appendix 1.
2.1.1 Wiring over the LAN
The following figures show the two ways of cable connection of a network PTZ
camera and a computer:
Purpose:
To test the network PTZ camera, you can directly connect the network PTZ
camera to the computer with a network cable as shown in Figure 2-1.
Refer to the Figure 2-2 to set the network PTZ camera over the LAN via a switch
or a router.
