User Manual of Network Mini PTZ Camera
© Hikvision
95
Figure 8-7 Recording Schedule Interface
2. Check the checkbox of Enable Record Schedule to enable scheduled recording.
3. Set the record parameters of the PTZ camera.
Figure 8-8 Record Parameters
Pre-record: The time you set to start recording before the scheduled time or
the event. For example, if an alarm triggers recording at 10:00, and the
pre-record time is set as 5 seconds, the PTZ camera starts to record at
9:59:55.
The Pre-record time can be configured as No Pre-record, 5 s, 10 s, 15 s, 20 s,
25 s, 30 s or not limited.
The pre-record time changes according to the video bitrate.
Post-record: The time you set to stop recording after the scheduled time or
the event. For example, if an alarm triggered recording ends at 11:00, and the
post-record time is set as 5 seconds, the PTZ camera records until 11:00:05.
The Post-record time can be configured as 5 s, 10 s, 30 s, 1 min, 2 min, 5 min
or 10 min.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DE3304W-DE and is the answer not in the manual?

HIKVISION DS-2DE3304W-DE Specifications

General IconGeneral
IK codeIK10
Form factorDome
Mounting typeCeiling/wall
Product colorWhite
International Protection (IP) codeIP66
TypeIP security camera
CertificationFCC, CE, UL, IEC/EN 61000, IEC/EN 55022, IEC/EN 55024, IEC /EN60950-1
Languages supportBUL, CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HRV, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR, VIE
Alarm input/outputYes
Number of languages32
Placement supportedIndoor & outdoor
Connectivity technologyWired
Sustainability certificatesRoHS
Operating temperature (T-T)-30 - 65 °C
Operating relative humidity (H-H)0 - 90 %
AC input voltage36 - 57 V
DC output current1 A
DC output voltage12
Power source typeDC, PoE
Power consumption (max)8 W
Number of cameras1
Wi-FiNo
Number of users32 user(s)
Cabling technology10/100Base-T(X)
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Number of simultaneous live view channels20 channels
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size128 GB
Total megapixels3 MP
Maximum resolution2048 x 1536 pixels
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology3D noise reduction
Pan range0 - 350 °
Pan speed60 °/sec
White balanceATW, Auto, Daylight, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range0 - 90 °
Camera shutter speed1/1 - 1/10000 s
Minimum illumination0.01 lx
Signal-to-Noise Ratio (SNR)52 dB
Digital zoom16 x
Optical zoom4 x
Focal length range2.8 - 12 mm
Maximum aperture number2.7
Minimum aperture number1.6
Sensor typeCMOS
Optical sensor size1/2.8 \
Weight and Dimensions IconWeight and Dimensions
Height107.2 mm
Weight950 g
Diameter140.7 mm
