11.
Set linkage method. See Linkage Method Sengs .
Direcon
Select the vehicle moving direcons that trigger alarms.
What to do next
Go to Picture to search and view the captured pictures. When you select File Type as Vehicle
Detecon, you can search the pictures by license plate No.
3.3.2 Picture Sengs
Captured vehicle pictures are uploaded. Picture size, quality and overlay informaon are
congurable.
Go to Open Plaorm → Road Trac → Picture to start.
Picture Type
Select one or more picture types to upload. Background picture, close-up of license plate or target,
and picture of the vehicle are available.
Picture Quality Vs Picture Size
Both Picture Quality and Picture Size aect the size and quality of pictures for uploading. They
cannot be set at the same me.
Picture Quality
The quality of the uploaded pictures is in accordance with the set value. Higher value means
clearer image. To maintain the quality, the size of the pictures may vary according to the image
complexity.
Picture Size
The size of the uploaded pictures is in accordance with the set value. To maintain the size,
pictures with more complex contents might be less
sasfactory in quality than that with simpler
contents.
Overlay
With Overlay enabled, every uploaded picture has an addional part to display the overlaid
informaon.
Font Color
The font color of overlaid texts.
Background
The background color for the overlaid texts.
Text Overlay
Check the desired items to display on the picture. The display sequence is adjustable.
Network Speed Dome User Manual
10

HIKVISION DS-2DF8C842IXS-AELW Specifications

General

Camera Type	PTZ
Max. Resolution	3840 × 2160
Tilt Range	-15° to 90°
Preset	256
Ingress Protection	IP66
Image Sensor	1/1.8" Progressive Scan CMOS
Zoom Speed	3.5 s (optical zoom, wide to tele)
Min. Illumination	0 Lux with IR
Pan Range	360°
Tilt Speed	0.1° - 120°/s
Video Compression	H.265/H.264/MJPEG
Audio Compression	G.711/G.726/PCM
Network Interface	RJ45 10M/100M Ethernet port
Power Supply	24 V AC
Operating Conditions	-40 °C to +70 °C; Humidity 95% or less (non-condensing)
Dimensions	Φ 220 mm
Bit Rate	32 Kbps to 16 Mbps
Frame Rate	50 Hz: 25 fps (3840 × 2160); 60 Hz: 30 fps (3840 × 2160)
