2.2 Installing Camera
The anti-corrosion camera installation adopts 12V DC power
supply. Pick appropriate site for junction box installation to
ensure the stable power and water-proof performance.
2.2.1 Wall Mounting
Steps:
1. Loosen the screws of the PT joint and separate the PT joint
top from the PT joint bottom.
PT Joint Top
PT Joint Bottom
Bracket
Separate PT Joint
2. Install the bracket.
1). Drill four screw holes (Φ10 mm, depth: 55 mm) on the wall
according to the bracket base.
2). Loosen the M8 expansion bolt and insert the bolt into the
wall.
3). Fix the bracket body with the expansion bolts.
To Next Page
